4000bph Automatic Pet Plastic Bottle Blow Moulding Machine
4000BPH Automatic PET Plastic Bottle Blow Moulding MachineThe machine with 4 cavities is specially designed to produce water bottole, PET bottle with high heat resistance for hot filling package such as juice and tea. It adopts multiple blowing to reduce the residual stress, as result shaped bottle ......
Send Inquiry
Product Description
The machine with 4 cavities is specially designed to produce water bottole, PET bottle with high heat resistance for hot filling package such as juice and tea. It adopts multiple blowing to reduce the residual stress, as result shaped bottle has slight shrinkage during hot filling.
In addition, crystallization varies with different mold design, as a result, the PET bottle produced can stand temperature over 90°C depending on the type of PET material with different crystallization rate. The neck up blowing mode protects the bottle preform from damage during blowing and ensures stable performance. With high strength, good transparency and low production costs, abundant material resource, It plays a big role in hot filling package market.
| Item | SKY-2L-4 | |
| Bottle type specification | Cavity | 4 |
| Theoryoutput | 4000-5000 | |
| Max. volume | 2L | |
| Bottle mouth maximum overall diameter | 28-38mm | |
| Bottle biggest diameter | 100mm | |
| Bottle maximum height | 330mm | |
| Power specifications | Light tube quantity | 32pcs |
| Light tube power | 1.25KW | |
| Maximum heating power | 40KW | |
| All electric machine installation | 43KW | |
| Actual consumption | 21.5KW | |
| Air pressure specification | Work pressure | 7-9kg/cm2 |
| Low-pressure gas consumption | 1600L/min | |
| Blow bottle pressure | 25-35kg/cm2 | |
| Higher -pressure gas consumption | 3000Ltr/min | |
| Frozen water specification | Work pressure | 5-6 kg/cm2 |
| Temperature range | 10 | |
| Consumption | 8000kcal/hr | |
| Frozen water flow | 88L/min | |
| Machine specification | Size of the machine | 4.5x1.6x1.9 |
| Weight of the machine | 3.5ton | |
Configuration list
| PLC controller PLC | MITSUBISHI |
| Touch screen | MITSUBISHI |
| Cylinder | SMC, Japan SMC |
| Filter | TPC, Korea TPC |
| Magnet valve | TPC, Korea TPC |
| Photoelectric switch | OMRON,Japan |
| Contactor | Schneider,France |
| Proximity switch | SICK ,German |
| Sensor | OMRON,Japan |
| Switch power | MEANWELL,Taiwan |
| Frequency converter | Mitsubishi,Japan |
| Main Servo motor | XINJIE CHINA |
| Feeding Servo Motor | XINJIE CHINA |
Package: standard export wooden case
Manufacture time: 30~60 days after signing the contract
Installation and adjustment time: one week at least
Guarantee time: 12months after machines running in buyer's factory.
