Full-Auto Plastic Lubricate Oil Drum Blow Molding Machine
Full-auto plastic lubricate oil drum blow molding machineA. Machine model: TCY70IIB. Capacity: Depending bottle shapeC. Suitable products: Pharmaceutical bottleD. Ball material: PE, HDPE, PPE. Usage: For drug packingAuto blow molding machine is link with Germanic technology, we are specializing in p......
Send Inquiry
Product Description
Full-auto plastic lubricate oil drum blow molding machine
A. Machine model: TCY70II
B. Capacity: Depending bottle shape
C. Suitable products: Pharmaceutical bottle
D. Ball material: PE, HDPE, PP
E. Usage: For drug packing
Auto blow molding machine is link with Germanic technology, we are specializing in producing and selling Plastic blow molding machine, such as plastic bottle, tank, Jerrycans, toolbox, abnormal blow molding piece, motorcar oil box, tray, etc., which is range from 10ML to 220L.
We supply single, double, multi-mould and single, double layers, multi-layers composite mould according to the customers requirements. We have lots of experiences in this line for ten years, we possess large number of skilled workers and technical stuffs which has fruitful practice experience, and also they have assembling` and servicing for more than two thousand consumers.
Any question,please call me.
MOB&waspp: +8613773240086
A. Machine model: TCY70II
B. Capacity: Depending bottle shape
C. Suitable products: Pharmaceutical bottle
D. Ball material: PE, HDPE, PP
E. Usage: For drug packing
Auto blow molding machine is link with Germanic technology, we are specializing in producing and selling Plastic blow molding machine, such as plastic bottle, tank, Jerrycans, toolbox, abnormal blow molding piece, motorcar oil box, tray, etc., which is range from 10ML to 220L.
We supply single, double, multi-mould and single, double layers, multi-layers composite mould according to the customers requirements. We have lots of experiences in this line for ten years, we possess large number of skilled workers and technical stuffs which has fruitful practice experience, and also they have assembling` and servicing for more than two thousand consumers.
| Basic parameter | Material | PE.PP... | |||
| Max.product volume | 5L | ||||
| Cycle time | 300pcs | ||||
| Measurement | LXWXH=3.5x2.2x2.8 (meter) | ||||
| Weight | 6T | ||||
| General power | 33.9KW | ||||
| Average power consumption | 22KW/H (The is the exactly power consumption) | ||||
| Plasticizing system | Specification | extrusion system can be applicable to various of raw material, plasticizing capability is good and output is high,transducer adjust speed,collect temperature-control signals and prevent the screw from cold starting | |||
| Speed reducer | hard-teeth, low noise and wear-resistant speed reducer | ||||
| Machine barrel screw | Ø70mm,L/D=24, 38CrMoALA high quality nitriding steel | ||||
| Plasticizing | 85Kg/H(HDPE) | ||||
| Heating zone | 4 zone | ||||
| Heating power | 16KW/H | ||||
| Extrude motor power | three phase a synchronism(380V.50HZ) | ||||
| cooling fanner | 4 zone power:85W | ||||
| Extrusion system | Specification | Patented central material feeding mold head that is quick in changing colors | |||
| Die head | 40Cr high quality nitriding steel | ||||
| Structure of die head | Shan Tou | ||||
| Mold center distance | -- | ||||
| Max diameter of die heat | Ø145mm | ||||
| Heating zone | 4 zone | ||||
| Heating power | 16KW | ||||
| Opening and clamping mold | Specification | Gear wheel and rack in-phase aim at twin shaft clamping device and cylinder | |||
| clamping force | 105KN | ||||
| Distance of mold platen | 188-538mm | ||||
| mold platen dimension | WXH:338x450mm | ||||
| Max mold dimension | WXHX:450x500 | ||||
| mold fix mode | bolt compaction | ||||
| Electric control system | Specification | PLC.colo.touch screen,standardization blowing shaping machine control system (MITSUBISHI programmable controller) | |||
| human-machine | color touch screen,trouble auto alarm, diagnose the system | ||||
| Temperature control | self-regulation | ||||
| Temperature control | adopt Japanese Mitsubishi PLC control system | ||||
| protection function | Automatic alert and breakdown feedback double protection of mechanical apparatus | ||||
| Hydraulic system | Specification | proportion pressure controller changing direction quickly and softly | |||
| human-machine electromotor | three phase a synchronism (380V,50HZ),11KW | ||||
| Hydraulic pump | adopt double-lamina pump | ||||
| Hydraulic valve | imported hydraulic components | ||||
| Vitta | high pressureVitta | ||||
| system pressure | 60Kg/cm² | ||||
| cooling mode | Water-cooled | ||||
| Pneumatic system | Specification | imported and famous brand pneumatic pressure | |||
| Air pressure | 0.6Mpa | ||||
| Air | 0.7M 3 /min | ||||
| Valve | FESTO | ||||
| Cooling system | Specification | mold,barrel,oil box adopt independentcooling waterway | |||
| cooling medium | water | ||||
| Water flux | 60L/min | ||||
| Water pressure | 0.3MPa | ||||
Any question,please call me.
MOB&waspp: +8613773240086
